| Təsvir | |
| İstehsalçı | Asus |
| Model |
B150M-K |
| Texniki göstəricilər | |
| Prosessor | Intel® Socket 1151 for 6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
| Çipset | Intel® B150 |
| Operativ yaddaş | 2 x DIMM, Max. 32Gb, DDR4 2133 MHz Non-ECC, Un-buffered Memory |
| Qrafika | Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : DVI-D/RGB ports - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz Maximum shared memory of 1024 MB Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ |
| Qoşulma | 1 x PCIe 3.0/2.0 x16 (x16 mode, (Gray)) 2 x PCIe 3.0/2.0 x1 |
| Şəbəkə | Realtek® RTL8111H, 1 x Gigabit LAN Controller(s) |
| USB portlar | Intel® B150 chipset : 6 x USB 2.0/1.1 port(s) (2 at back panel, (Black), Type-A, 4 at mid-board) Intel® B150 chipset : 6 x USB 3.0/2.0 port(s) (4 at back panel, (Blue), Type-A, 2 at mid-board) |
| Əməliyyat sisteminin dəstəyi | Windows 7 32-Bit/64-Bit Windows® 10 64-Bit Windows® 8.1 64-Bit |
| Arxa paneldə konnektorlar | 1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x DVI-D 1 x D-Sub 1 x LAN (RJ45) port(s) 4 x USB 3.0 ((Blue)) Type-A 2 x USB 2.0 3 x Audio jack(s) |
| Platada girişlər | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x Clear CMOS jumper(s) |
| Əlavə | |
| Form-faktor | 22.6 x 18.3 |
| Zəmanət | 12 мес. |
